JVC DVD/CD Monitor w/Bluetooth/USB/iPhone/Android For 2002 Volkswagen Golf

Package Includes:

• (1) JVC KW-V25BT 6.2" Car DVD/CD Receiver Bluetooth Monitor Sirius XM/iphone/Android
• (1) METRA 95-9012 1999-2006 Volkswagen VW Double-Din Dash Radio Installation Kit
• (1) Axxess XSVI-9003-NAV 2002-2017 Volkswagen VW CAN Wire Harness Interface RAP
• (1) Metra 40-EU55 2002-08 VW/BMW Powered Antenna Adaptor 2002 and Up

---

Features of KW-V25BT:

• JVC KW-V25BT In-Dash Receiver
• CEA-2006 compliant amplifier
• Power Output:
  Peak: 50 watts x 4 channels
         RMS: 22 watts x 4 channels
• Theft-deterrent, detachable face plate: Optional Receiver Faceplate Case Available
• CD text information display
• 6.2" WVGA Clear Resistive Touch Monitor
• MP3 ID3 Tag Display (Title/Artist/Album)
• AM/FM tuner with 18FM/6AM presets
• JVC RM-RK258 Optional Remote Control Sold Separately
• JVC Remote Control App Available
• Authorized Internet Dealer
• 1-year Manufacturer's Warranty

Playback and Audio Features:

• CD/CD-R/RW, DVD/DVD-R/DVD-RW, MP3/WMA/AAC Playback
• MP3/WMA/AAC/MPEG/FLAC Playback via USB
• Compatible with Apple iPhone 6/6+ and iOS 8 software
• Pandora/iHeartRadio/Spotify Control via Android and iPhone
• 13-band graphic equalizer with Volume Link EQ (10 Preset + 1 User)
• 3.5mm Front Audio Auxiliary Input
• Front, Rear, Front and Rear USB Input
• (8GB) SD Card reader for (audio and video) playback
• 3 Sets of 2.5V preamp outputs (front, rear and subwoofer)

Bluetooth Features:

• Built-in Bluetooth technology for hands-free talking and audio streaming
• Bluetooth version 3.0+EDR certified
• 2 Phones Full-Time Connection
• Bluetooth Profiles Supported:
   HFP: Hands Free Profile allows a hands-free car kit to connect to a compatible mobile phone
  HSP: Headset Profile enables a Bluetooth headset to connect to a compatible mobile phone
  PBAP: Phone Book Access Profile allows the car stereo to display the name of the incoming caller, as well as access the contact list of the mobile phone directly from the car stereo
  A2DP: Advanced Audio Distribution Profile allows high quality audio to be streamed from an audio device to the car stereo
  AVRCP: Audio/Video Remote Control Profile supports basic remote control functions (play, pause, etc) via Bluetooth
  SPP: Serial Port Profile provides a wireless replacement for RS-232 based serial communications
  SIRI: Eyes Free Mode for iPhone and iPhone
• Works with most Bluetooth enabled cell phones
• Includes a external wired microphone for clear, convenient, distortion-free talking
• Maximum communication rage: 32.8 feet (approx, line of sight)

Expandability Options:

• SiriusXM Satellite Radio Ready: SiriusXM SXV300v1 and subscription required, sold separately
• HD Radio Built-in
• Steering Wheel Control Ready: PAC ControlPRO or the Axxess ASWC-1 required and sold separately
• Dedicated Backup Camera Input: Used for universal rear view cameras with an RCA composite input.
• Rear RCA Video Output: Used for connection to separate monitors and other devices
• Rear RCA Audio/Video Input: Used for connecting video accessories such as game consoles, video cameras, etc.

---

Authorized Metra Dealer!

Features:

• METRA 95-9012 1999-2006 Volkswagen VW Double-Din Dash Radio Installation Kit
• ISO DDIN radio provision
• Wiring and Antenna Connections (sold separately):

• Wiring Harness: 70-1784 ; XSVI-9003-9003-NAV

• Antenna Adapter: 40-VW54 ; 40-EU55

Applications:

• Volkswagen:

• Golf 1998-2006

• GTI 1998-2005

• Jetta 1998-2005

• Passat 2000-2005

---

The XSVI series interface is an inexpensive solution that provides +12-volt accessory power output for select vehicles that data control signals instead of conventional power signals. If the vehicle is equipped with retained accessory power features, the XSVI will keep those features. Also provides outputs for Speed Sense, Reverse, and Parking Brake.

Features:

• Axxess XSVI-9003-NAV 2002-2017 Volkswagen VW CAN Wire Harness Interface RAP
• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (Retained Accessory Power)

• Used in non-amplified systems or when replacing amplified system

• Provides NAV outputs (Parking Brake, Reverse, Mute, and Speed Sense)

• ASWC-1 harness included (ASWC-1 not included)

• High level speaker input

• USB updatable


Applications:

• VOLKSWAGEN CC 2009 2011

• VOLKSWAGEN Eos 2006 2012

• VOLKSWAGEN GLI 2008 2008

• VOLKSWAGEN Golf 2002 2009

• VOLKSWAGEN GTI 2002 2010

• VOLKSWAGEN Jetta 2002 2009

• VOLKSWAGEN Passat 2002 2009

• VOLKSWAGEN Rabbit 2006 2009

• VOLKSWAGEN Tiguan 2009 2009

---

ADVANTAGES OF METRA ANTENNA ADAPTORS:

• These are heat resistant so they will last a lifetime
• Precision hand assembled terminals are pressure sensitive, and do not break easily like the cheaper ones
• The ends of the turbowires are pre-stripped so installation is quick and easy
• High quality plastic connectors always fit perfectly.
• OEM Quality terminals!  This makes a secure connection between the terminals and the connectors
• Lifetime Warranty
• Made with the highest quality and precision out of any other brand
• Color coded wires matches aftermarket radios for an easy install
• Will make your factory antenna work perfectly with an aftermarket receiver
• Included is installation instructions!

Features:

• Powered antenna and newer "FACRA" style connector to aftermarket radio
