Memphis Audio MOJO 612D2 12" 3000 Watt Competition Car Subwoofer DVC 2 ohm Sub

$869.95 $399.58 Save 54% Sold out
Shipping calculated at checkout.
Condition: Open Box
Product Description

Description:

MOJO6 subwoofers are the most powerful earthshaking subwoofer in the Memphis line. Capable of handling massive amounts of power and shelling out thunderous bass, the MOJO6 subwoofers is the most impressive Memphis subwoofer to ever hit the street.

Features:

  • Memphis Audio MOJO 612D2 12" 3000 Watt Competition Car Subwoofer DVC 2 ohm Sub
  • Vented cast aluminum basket
  • 4-layer CCAW 3.5" voice coil
  • 235oz magnet
  • Fiberglass reinforced cone
  • Double stitched rubber surround
  • Reinforced double spider
  • Heat dissipating aluminum heat sink
  • Single sided terminal block
Specifications:
  • Size (in): 12"
  • RMS Power (w): 1500
  • Peak Power (w): 3000
  • Sensitivity (dB): 81
  • Magnet Size (Oz): 235
  • Mounting Depth (in): 8.58
  • Cut Out Diameter (in): 10.7
  • Voice Coil Diameter (in): 3.5
  • Warranty: 1

TS Parameters:

THIELE SMALL PARAMETERS
Resonant Frequency  (fs) 37.6 Hz
Mechanical Q 4.863 Qms
Electrical Q 0.943 Qes
Total Q 0.79 Qts
Sensitivity  81 dB
Xmax Linear 0.669 in.
Displacement 0.317 cf.
Air volume of suspension (Vas) 16.42 cf.
Moving Mass (Mms) 405.449 g
Suspension Compliance (Cms) 0.044 mmN
Effective piston area (Sd) 510.71 SqCm
Motor Strength (Bl) 10.323 TM
VOICE COIL & MAGNET
Impedance Series 4 ohms
Impedance parallel 1 ohms
Voice coil diameter 3.5 in.
RMS Power 1500 Watts
Peak Power 3000 Watts
Magnet weight 235 oz
Magnet diameter 8.66 in.
PHYSICAL DIMENSIONS
Mounting depth 8.58 in.
Cutout Diameter 10.7 in.
Frame Outside Diameter 12.67 in.
ENCLOSURE RECOMMENDATIONS
Single sub sealed 1.5 cf.
Dual subs Sealed 3 cf.
Single sub vented 3.25 GROSS cf.
Port dimensions
