Hifonics BE35-800.4 800 Watt 4-Channel Amplifier Super A/B Class Car Audio Amp

What's in the Box?

• Amplifier

• Owner's Manual


Description:

Hifonics 35th Anniversary 4 x 200 Super A/B Class™ Brutus Elite four channel car audio amplifier with electronic crossovers.

Hifonics offers Super A/B Class™ full range and Super D-Class™ mono subwoofer amplifiers to continue the 35th Anniversary celebration of Hifonics. The Brutus ELITE or “BE35” offers several 2 and 4 channel full range with several mono amps along with a killer 5 channel that utilizes both Super A/B Class™ and Super D-Class™ in the same amplifier – the best part is the 5th channel is 1 ohm stable, which is unheard of in five channel high performance amplifiers. The big bruiser in the line is the Brutus BE35 4000.1D delivering 4000 watts at 1ohm.

Features:

• Hifonics Elite products are not available for Internet sales

• Accu-Cross crossovers allow complete control of the signal direction to all speakers

• Ultra-Fi™ MOSFETs product high power with high efficiency for coolig and minimal distortion

• Tiffany style RCA connectors for audiophile signal quality with minimum distortion

• Illuminated molded ad angled output connectors

• Super D-Class mono blocks include bass remote

• Low Noise Preamplifier Circuitry

  • Maximum low voltage signal from the source unit comes into the amplifier through a low voltage circuit which delivers minimal distortion through the amplification process

• RCA Inputs

  • Tiffany style RCA connectors for audiophile signal quality and maximum signal throughput with minimum distortion and maximum external noise rejection

• Operation Mode

  • Flexible installation allows this amplifier to run in four channel or bridged mono mode

• Crossover Type

  • Accu-Cross crossovers allow for complete control of the signal directing to all speakers. See specifications section for specific frequencies

• Electronic Equalizer

  • Control of amplifier output with on board electronic crossover to tailor specific frequencies to speakers and subwoofers. Check specifications for specific frequencies for this amplifier

• Class / Topology

  • Developed over three decades of engineering to deliver the highest level of sound quality and power efficiency. At very high listening levels. Hifonics Super A/B Class results in lower distortion, higher current efficiencies and less heat than conventional amplifier designs

• Output Device Technology

  • The Ultra-Fi™ MOSFET is designed for music production vs just electronics output power. It produces very musical high power with high efficiency for cooling and minimal distortion

• Heat Sink

  • Heavy duty aluminum alloy heat-sink efficiently moves heat from the MOSFET where it can be cooled

• Power Supply

  • The Twin Turbo Coil PS is a Pulse Width Modulated power supply keeps voltage constant through the Ultra-Fi output devices

• Output Connections

  • Nickel-plated, high temperature impact resistant with hex screw terminals that allow for secure connections and is erosion resistant

• Connection Type

  • Secure connection for all power, ground and speaker connections. Angled for ease of access during installation.

• Full-Range RCA Outputs for Signal Pass Through

  • One pair of Tiffany style connectors for a full range, L & R output allow distortion free signal to be passed through this amplifier to feed that signal to other components without the need for noise generating Y cables

• LED System Protection Circuitry Diagnostics

  • Monitor overload and speaker short protection with illuminated indicators on the amplifier end panel

• Bass Remote Included

  • Wired Bass Remote allows adjustments to bass frequencies from the control which can be mounted anywhere in the vehicle. Smooth potentiometer and ringed illumination in a satin black mount create a custom look


Specifications:

• Class: Super A/B Class™

• Variable Voltage: 0.2V - 6V

• Signal to Noise: >85dB

• Frequency Response: 20Hz - 35kHz

• Crossover: Electronic

• Variable High Pass Crossover 12dB per Octave: 10Hz - 1.5KHz

• Variable Low Pass Crossover 12dB per Octave: 30Hz - 500Hz

• Tone Control/Parametric EQ: Bass EQ

• Bass Boost: 0~9dB@45Hz

• Power @ 2 Ohms: 4 x 200 Watts

• Power @ 4 Ohms: 4 x 100 Watts

• Mono Bridged @ 4 Ohms: 2 x 400 Watts

• Total Channels: 4

• Audio Inputs: Yes

• Power Terminal 12v/GND: 4 AWG

• Speaker Terminal Wire Gauge: 12 AWG

• Total Harmonic Distortion (THD): <0.05%

• Warranty: 1 Year


Product Dimensions:

• Product ONLY Weight (pounds): 8.8

• Product ONLY Weight (kilograms): 3.99

• Product Packaging Weight (pounds): 10.3

• Product Packaging Weight (kilograms): 4.67

• Product Packaging Dimensions (LxWxH) - Inches: 19.75 x 10.13 x 3.56

• Product Packaging Dimensions (LxWxH) - CM: 50.17 x 25.73 x 9.04
