American DJ Vintage Bar RGBL LED DMX Eye Candy Amber Blinder Effect Light ADJ
AMERICAN DJ
American DJ Vintage Bar RGBL LED DMX Eye Candy Amber Blinder Effect Light ADJ
American DJ Vintage Bar RGBL LED DMX Eye Candy Amber Blinder Effect Light ADJ
35.75" Amber Blinder Bar, 4x150W COB Amber LEDs, 120 RGBL Background LEDs, Includes Omega Clamps
Free Shipping
Features
- Four 150W amber COB LEDs at 2000K for retro blinder looks
- 120 RGBL background LEDs split into 20 pixel groups
- More than 27,000 lumens across a 160 degree field angle
- Strobe from 0.5 to 33Hz with quiet, flicker free operation
- DMX, RDM, sACN, Art-Net, and Aria X2 wireless control
Couldn't load pickup availability
What's Included in the box
- 1x Vintage Bar fixture
- 2x Adjustable feet with 108mm omega clamp receivers
- 2x 108mm Omega clamps
- 1x IP65 locking power cable
SKU: SKU: Vintage Bar
View full details






Product Description
Features
Two Fixtures In One Body
Four 150W amber COB LEDs handle retro blinder looks while 120 RGBL LEDs cover color effects, so one bar does the work of two hangs.
Warm Tungsten Character
The amber COB source runs at 2000K with over 27,000 lumens, giving the deep golden glow of vintage blinders instead of a white LED approximation.
Pixel Mapped Color
Twenty individually controllable pixel groups let you run chases, gradients, and background patterns across the face of the bar from a console.
Control Any Way You Rig
DMX512, RDM, sACN, and Art-Net cover wired control across ten channel modes, while Aria X2 adds wireless management and over-the-air firmware updates.
Rigs Or Stands
Included adjustable feet and two 108mm omega clamps mount it on truss or set it on the deck, with the optional VFB1 base for vertical use.
Technical Specifications
- Product Type Amber Blinder and RGBL Effect Bar
- Primary Light Source 4 x 150W high-power COB amber LEDs
- Primary Color Temperature 2000K
- Lumens Greater than 27,000
- Illuminance 647 lux at 5 meters
- CRI 70
- Field Angle 160 degrees
- Background Light Source 120 x 0.8W SMD 5050 RGBL LEDs
- Pixel Groups 20 groups of 6 LEDs
- Dimming 0-100% linear dimming
- Strobe 0.5 to 33Hz
- Additional Features Aria X2 management system, flicker free, silent operation, interlocking fixtures
- Display OLED with 4-button touch menu
- DMX Channel Modes 5, 6, 8, 14, 17, 18, 84, 88, 90 and 97 channels
- Protocols DMX512, RDM, sACN, Art-Net
- Control Modes Primary/Secondary synchronization, stand-alone, DMX512
- DMX Connections IP20 5-pin DMX input and thru
- Network Connections IP20 RJ45 Ethernet
- Power Connections IP65 locking power input and thru
- Power Consumption 780W at 120V, 750W at 230V
- Power Link 1 unit at 120V, 2 units at 230V
- Voltage AC 100-230V, 50/60Hz
- Optional Accessories VFB1 floor base, VFB1-VBA adapter, 180mm omega bracket
- IP Rating IP20, indoor only
- Certifications cETLus, CE, FCC
- Weight 41.89 lb
- Dimensions (LxWxH) 35.75" x 11.50" x 10.12" (908 x 292 x 257mm)
