American DJ Vintage X RGB LED DMX Eye Candy Amber Blinder Effect Par Light ADJ
AMERICAN DJ
American DJ Vintage X RGB LED DMX Eye Candy Amber Blinder Effect Par Light ADJ
American DJ Vintage X RGB LED DMX Eye Candy Amber Blinder Effect Par Light ADJ
Octagonal Amber Blinder Par, 4x60W Amber LEDs, 64 RGB Background LEDs, IP65 Locking Power Cable
Free Shipping
Features
- Four 60W amber foreground LEDs at 2000K for blinder looks
- Sixty-four 3W RGB background LEDs, individually controllable
- White color temperature control from 2,700K to 10,000K
- Coffin lock system interlocks up to eight fixtures
- DMX512, Bluetooth, RDM, and Aria X2 wireless control
Couldn't load pickup availability
What's Included in the box
- 1x Vintage X fixture
- 1x IP65 locking power cable
SKU: SKU: Vintage X
View full details




Product Description
Features
Blinder And Color In One
Four 60W amber LEDs deliver the warm 2000K blinder look while 64 RGB LEDs fill the octagon face with color, covering two roles from one hang.
Every LED Under Control
All foreground and background LEDs are individually controllable over DMX, so you can map patterns and chases across the octagon shape.
Wide Short-Throw Coverage
A 140 degree beam and 150 degree field angle spread 7,000 to 8,000 lumens over a large area from close range on stage or a set.
Build Bigger Shapes
The coffin lock system joins up to eight fixtures into one solid block, turning individual pars into a larger scenic lighting element.
Wireless Where It Helps
Bluetooth and the Aria X2 system add wireless control and over-the-air firmware updates on top of standard DMX512 and RDM connections.
Technical Specifications
- Product Type Amber Blinder and RGB Effect Par
- Foreground Light Source 4 x 60W amber LEDs at 2000K (+/- 50K)
- Background Light Source 64 x 3W RGB LEDs
- LED Life 50,000 hour average
- Output 220 lux, 7,000 to 8,000 lumens
- White Color Temperature Range 2,700K to 10,000K (RGB LEDs)
- Beam Angle 140 degrees
- Field Angle 150 degrees
- Pixel Control All LEDs individually controllable via DMX
- Built-In Programs Foreground and background LED programs
- Strobe Electronic, 0.1Hz to 20Hz
- Dim Modes 6 user selectable
- Dim Curves 4 user selectable
- Refresh Rates User selectable, 900Hz to 25kHz
- Control DMX512, Aria X2 wireless management, Bluetooth, RDM and RDM Net compatible
- DMX Channel Modes 10, 16, 25, 42, 47, 196, 203, 210, 214 and 218 channels
- Control Modes On-board manual, Primary/Secondary, DMX
- DMX Connections 5-pin XLR in/out
- Power Connections IP65 locking power in and thru
- Power Consumption 200W
- Power Link 2 units at 120V, 4 units at 230V
- Voltage AC 100-240V, 50/60Hz
- Housing IP20 metal housing with safety eyelet, digital display, adjustable hanging bracket and omega clamp receivers
- Operating Temperature -4F to 113F (-20C to 45C)
- Optional Accessories 107mm omega clamp
- Certifications CE, cETLus, FCC
- Weight 18 lb
- Dimensions (LxWxH) 15.7" x 15.7" x 7.6" (398 x 398 x 194mm)
