DRM12A-P Passive Arrayable PA Speaker with 3 V7 Switch Mics
DRM12A-P Passive Arrayable PA Speaker with 3 V7 Switch Mics
12-Inch Speaker, 500W Continuous, 3 Supercardioid Dynamic Mics
Free Shipping
Features
- 2000W 12-inch arrayable passive speaker for live sound and production
- Includes three V7 Switch supercardioid handheld microphones
- 20° vertical by 110° horizontal coverage pattern
- Dual-angle pole mount, seven M10 flypoints, and integrated flying hardware
- 15 mm plywood cabinet with internal bracing and steel grille
Couldn't load pickup availability
What's Included in the box
- (1) DRM12A-P 12-Inch 2000W Arrayable Passive Live Sound DJ PA Speaker
- (3) V7 Switch Supercardioid Handheld Microphones with Magnetic Switch
- Mic Clip
- Thread Adapter
- Spare Black Internal Windscreen
- Zipper Pouch
- Logo Sticker
SKU: SKU: DRM12A-P+(3) V7 Switch
View full details


















Product Description
Features
Clear Vocal and Bass Response
The 12-inch high-excursion woofer and triple 1-inch titanium-diaphragm compression driver array support increased bass response and clear vocal projection for live sound.
Coverage for Audience Areas
A 20° vertical by 110° horizontal pattern helps direct sound across audience areas in clubs, houses of worship, production spaces, and installations.
Mounting Choices for Each Venue
A dual-angle pole mount, seven M10 flypoints, and integrated flying hardware give crews placement options for portable rigs or installed setups.
Ready for Transport
The 15 mm plywood cabinet, internal bracing, textured coating, and powder-coated steel grille support repeat setup and transport for demanding live work.
Switch Control Without Clicks
Three supercardioid handheld microphones add recessed lockable switches and click-free reed operation for talkback, vocals, rehearsals, live performance, and stage use.
Technical Specifications
- Product Type Arrayable Passive PA Speaker Bundle with Three Microphones
- Speaker Driver Size 12"
- Power Handling (Continuous) 500W
- Power Handling (Program) 1000W
- Power Handling (Peak) 2000W
- Speaker Coverage 20°V x 110°H
- Speaker Inputs Parallel inputs
- Speaker Cabinet 15 mm plywood with internal bracing
- Speaker Grille Powder-coated heavy-gauge steel
- Speaker Mounting Dual-angle pole mount
- Speaker Rigging 7 x M10 flypoints, integrated flying hardware
- Mic Capsule Dynamic
- Mic Electrical Impedance 300 Ohms
- Mic Connectivity 3-pin male XLR connector
- Mic Polar Pattern Supercardioid
- Mic Frequency Range 40 Hz - 19 kHz
- Mic Sensitivity 2.0 mV / Pa (-54 dBV)
- Mic Magnet Neodymium
- Mic Voice Coil Aluminum
- Mic Switch Reed element
- Weight Speaker: 55.0 lb / 24.9 kg; microphone: 305 g (10.76 oz.) per microphone
- Dimensions Microphone: 54 mm diameter x 184 mm length (2.13 in. x 7.24 in.)
