Saber Spot DTW Compact 15W Warm White LED DMX Spotlight
AMERICAN DJ
Saber Spot DTW Compact 15W Warm White LED DMX Spotlight
Saber Spot DTW Compact 15W Warm White LED DMX Spotlight
15W Warm White LED Spot, 20-Degree Beam, Dim to Warm, DMX/RDM
Free Shipping
Features
- 15W warm white LED with dim-to-warm from 3100K to 1900K amber
- Built-in ACL lens produces a focused 20-degree beam angle
- DMX-512 and RDM control with three channel modes
- Flicker-free at 3.6 KHz refresh rate for camera-friendly output
- Two interchangeable frost filter lenses (10-degree and 45-degree)
Couldn't load pickup availability
What's Included in the box
- ADJ Saber Spot DTW Spotlight
- Interchangeable Frost Filter Lenses (2)
SKU: SKU: SABER SPOT DTW*
View full details



Product Description
DMX-512 control with three channel modes (1, 2, or 4) keeps programming simple, and RDM support lets you assign and configure the fixture remotely. Five selectable dimming curves, variable strobing from 1 to 20 Hz, and a 3.6 KHz refresh rate deliver flicker-free output on camera. Locking power connections let you daisy-chain up to 33 units at 120V, and two interchangeable frost filter lenses (10-degree and 45-degree) widen the beam when you need a softer spread. The scissor bracket mounts overhead or sits on the ground, and the metal black housing measures just 3.5" x 6.75" x 3.5" at 2.6 lb. A 4-button LED display on the rear panel handles all menu navigation.
Features
Dim-to-Warm Technology
Color temperature shifts from 3100K warm white to 1900K amber as you dim, replicating the natural curve of a halogen lamp.
Focused 20-Degree Beam
The built-in ACL lens throws a tight spot ideal for table lighting, retail accents, and stage highlights at 726 lux at 3 meters.
Flicker-Free on Camera
A 3.6 KHz refresh rate produces clean output for video and broadcast environments without banding or flicker.
Locking Power Daisy-Chain
Locking power in/out connections let you link up to 33 fixtures at 120V on a single circuit for fast, tidy rigging.
Compact and Lightweight
At 3.5" x 6.75" x 3.5" and 2.6 lb, the metal housing fits tight spaces and adds minimal weight to truss or ground setups.
Technical Specifications
- Product Type Compact LED Spotlight
- Light Source 15W Warm White LED
- Beam Angle 20 degrees
- Color Temperature 3100K (Warm White) / 1900K (Amber)
- LUX 726 @ 3M
- CRI 92
- DMX Channel Modes 1, 2, or 4
- Dimming Curves 5
- Strobe Rate 1-20 Hz
- Refresh Rate 3.6 KHz (Flicker Free)
- Included Frost Filters 10-degree and 45-degree
- Power Connections Locking In/Out
- Daisy Chain 33 @120V / 71 @230V
- Control 3-Pin DMX In/Out, RDM
- Input Voltage 100-240V 50/60Hz (Auto Sensing)
- Power Consumption 24W
- Dimensions (L x W x H) 3.5" x 6.75" x 3.5" / 88 x 170 x 87mm
- Weight 2.6 lb / 1.2 kg
