CVF18VJD

The Celestion CVF18VJD is an 18-inch subwoofer driver for cabinets that need to move serious air. It handles 1,600W AES and 3,200W continuous at 8 Ohm, with 97dB sensitivity and a 25Hz to 1,500Hz range that reaches into the sub-bass most PA systems only hint at. A 125mm copper voice coil is wound longer than the gap for better control at high excursion, and an airflow vented magnet assembly disperses heat so output holds steady through a long night. Twin demodulation rings keep inductance distortion down, which is what separates a defined bass line from a wall of noise. The cone is carbon and Kevlar loaded paper with a cloth-sealed surround and optimised double suspension, giving 12mm of Xmax with the alignment needed to stay linear. A cast aluminium chassis handles the mechanical load without flexing. Parameters (Fs 34.5Hz, Qts 0.309, Vas 145.81 litres, Bl 32.59Tm) point to vented and bandpass designs for touring subs, club installs, and large mobile rigs. Unit weight is 50.6 lb. Also available in 4 Ohm.
