Heritage G12-65 15 Ohm
Celestion
Heritage G12-65 15 Ohm
Heritage G12-65 15 Ohm
12" Ceramic Guitar Speaker, 65W, 15 Ohm, 97dB Sensitivity, Pressed Steel Chassis
Free Shipping
Features
- Faithful recreation of the late-1970s G12-65 built for 4x12 cabinets
- 65W power handling with fast attack and a tightly controlled low end
- Precisely tuned midrange and crisp, defined top end for aggressive crunch
- Midrange warmth adds weight and depth to single notes
- 15 Ohm rating matches original period cabinet wiring
Couldn't load pickup availability
What's Included in the box
- Celestion Heritage G12-65 12-inch Guitar Speaker, 15 Ohm
SKU: SKU: Heritage G12-65 15 ohm
View full details






Product Description
Features
A Genuine Period Recreation
Built to the original late-seventies design, this speaker gives restorers and vintage-spec builders the real G12-65 voicing rather than an approximation.
Fast Attack, Tight Bass
Quick transient response and a controlled low end keep riffs percussive at high gain, which is why hard rock players adopted it in the early eighties.
Crunch That Punches Through
A tuned midrange and crisp, defined top end push chord work forward in a band mix without needing extra volume from the amplifier.
Weight Behind Single Notes
Midrange warmth and detail give lead lines depth and body, so solos carry substance instead of sounding thin over a loud rhythm section.
Correct 15 Ohm Load
The 15 Ohm rating matches period cabinet and head wiring, keeping vintage builds authentic and impedance matching exactly as originally specified.
Technical Specifications
- Product Type 12-inch Ceramic Guitar Speaker
- Nominal Diameter 305mm / 12in
- Power Rating 65W
- Rated Impedance 15 Ohm
- Sensitivity 97dB
- Frequency Range 80-5000Hz
- Chassis Type Pressed Steel
- Magnet Type Ceramic
- Magnet Weight 0.99kg / 35oz
- Voice Coil Diameter 44mm / 1.75in
- Voice Coil Material Round Copper
- Resonance Frequency (Fs) 85Hz
- DC Resistance (Re) 11.8 Ohm
- Cut-out Diameter 283mm / 11.1in
- Mounting Holes 4 on 297mm / 11.7in PCD
- Weight 7.7 lb
- Dimensions 12.2in Diameter x 5in Overall Depth
