MTX 3510-02 10" Car Audio Subwoofer
MTX
MTX 3510-02 10" Car Audio Subwoofer
MTX 3510-02 10" Car Audio Subwoofer
10" Single Voice Coil Subwoofer, 250W RMS, 2 Ohm
Free Shipping
Features
- 10" single voice coil subwoofer rated 250W RMS
- 500W peak power handling at 2 ohm impedance
- Inverted Apex surround increases volume displacement and SPL
- Spider Plateau Venting targets cool air at the voice coil
- Progressive suspension controls excursion to reduce distortion
Couldn't load pickup availability
What's Included in the box
- (1) MTX 3510-02 10" Car Audio Subwoofer
SKU: SKU: 3510-02*
View full details






Product Description
The subwoofer's Inverted Apex surround increases surface area compared to a standard surround design, which allows for more air movement and translates directly into higher volume displacement and SPL. A progressive suspension controls cone excursion at high power, keeping distortion in check so the bass stays clean instead of breaking up as volume climbs. Spider Plateau Venting, a mechanical cooling process built into the spider assembly, targets cool air directly at the voice coil, managing temperature during long, loud sessions so output doesn't fade over time.
With a 28Hz to 130Hz frequency response and a recommended amplifier power of 125-250W RMS, the 3510-02 pairs easily with a mid-range mono amplifier. It fits a 0.75 cubic foot sealed enclosure or a 2.0 cubic foot vented box, giving buyers a straightforward path to adding real bass to a factory or aftermarket system without needing to plan a custom build.
Features
More Surface, More SPL
The Inverted Apex surround increases usable cone area over a standard surround, resulting in greater air movement and higher SPL from the same 10" footprint.
Clean Bass At High Power
A progressive suspension controls cone excursion as power increases, keeping distortion low so bass stays tight instead of breaking up at volume.
Built To Run Cool
Spider Plateau Venting routes cool air directly at the voice coil, managing temperature during extended, high-volume listening sessions.
Flexible Enclosure Options
A 28Hz-130Hz response works in either a 0.75 cubic foot sealed box or a 2.0 cubic foot vented enclosure, depending on available space.
Easy Mono Amp Pairing
A 125-250W RMS recommended amp range makes it simple to match this subwoofer with a mid-range mono amplifier
Technical Specifications
- Product Type Car Audio Subwoofer
- Subwoofer Size 10 in
- Voice Coil Configuration Single, 2 Ohm
- RMS Power Handling 250W
- Peak Power Handling 500W
- Recommended Amp Power 125W - 250W RMS
- Frequency Response 28Hz - 130Hz
- Sensitivity 83.2 dB
- Mounting Depth 4.625 in
- Cut Out Diameter 9.188 in
- Sealed Enclosure Net Volume 0.75 cu ft
- Vented Enclosure Net Volume 2.0 cu ft
