Power Acoustik
NB-1
NB-1
Niobium Dome Car Tweeters, 180W Max Each, 100W RMS, 4-Ohm, Built-In Crossovers, Pair Included
Features
- Pair of niobium dome tweeters rated 100W RMS and 180W max each
- No voice coil in the design, so there is no coil to burn out
- Polypropylene diaphragm with 5kHz to 25kHz frequency response
- Built-in crossover blocks low frequencies from reaching the tweeter
- Surface or angle mount with only 0.625" of mounting depth
Couldn't load pickup availability
What's Included in the box
- 2 x Power Acoustik NB-1 tweeters
- Surface/angle mounting hardware
SKU: SKU: NB1
View full details

Product Description
Sensitivity is rated 97 dB and frequency response runs 5kHz to 25kHz, putting the NB-1 in charge of cymbals, string detail, and vocal texture that larger speakers roll off. A built-in crossover blocks the low frequencies a tweeter is not meant to play, so you can wire the pair in without adding an external passive network.
Mounting is where these fit the widest range of vehicles. Surface and angle mounting are both supported, and mounting depth is just 0.625", so they go into door panels, A-pillars, sail panels, kick panels, dash corners, or custom pods without deep cutting. At 4 ohms they work with factory head units and aftermarket amplifiers alike, either added on top of coaxial speakers to sharpen the top end or used as the high-frequency section of a component front stage. The NB series has been in the Power Acoustik line for over a decade, and this listing is priced and packaged per pair.
Features
-
Highs That Stay Clear
A niobium rare-earth ferroelectric transducer with a polypropylene diaphragm reproduces 5kHz to 25kHz, filling in the detail factory speakers lose up top.
-
No Coil To Burn Out
The NB-1 works without a voice coil, so the failure point that ends most tweeters simply is not there, even at 100W RMS each.
-
Fits Nearly Any Panel
Surface or angle mounting with a 0.625" mounting depth lets these go in doors, A-pillars, sail panels, kick panels, or custom pods.
-
Wires In Without Extras
A built-in crossover keeps low frequencies out of the tweeter, so no external passive network is needed for a clean installation.
-
Loud With Little Power
97 dB sensitivity at 4 ohms means these come alive on a factory head unit and still handle a full aftermarket amplifier channel.
Technical Specifications
- Product Type Car Audio Tweeters (Pair)
- Max Power 180W Each
- RMS Power 100W Each
- Transducer Niobium Rare Earth Ferroelectric
- Diaphragm Polypropylene
- Frequency Response 5kHz - 25kHz
- Impedance 4 Ohm
- Sensitivity 97 dB
- Crossover Built-In
- Mounting Style Surface Or Angle Mount
- Mounting Depth 0.625"
