EPM8

The Soundcraft EPM8 is an analog mixing console built for live sound and recording work that calls for a clean signal path and simple, direct control. Eight mono input channels each carry a GB30 mic preamp with a 55dB gain range and +22dB of headroom, so quiet mics and hot line sources both sit comfortably without distortion. Two stereo channels take keyboards, playback decks, and other line-level gear, and switchable 48V phantom power runs condenser mics of any type.

Every mono channel gets 3-band EQ with a swept midrange, letting you pull problem frequencies out of vocals and drums rather than working around them. Stereo channels use 2-band EQ. TRS insert points on all mono inputs and the mix output leave room for outboard compressors and gates. Two configurable aux buses cover monitor sends and effects, and ten-segment LED output metering gives a clear read on level before the signal leaves the desk.

The PEAK LED watches several points along the channel strip at once and lights more brightly as the signal approaches clipping, so you catch overload where it happens. 60mm faders, the same ones used on larger Soundcraft desks, give fine control over level. Monitor and headphone outputs run in parallel, so a performer can listen on headphones while an engineer works on studio monitors.

Surface-mount construction with close-tolerance components keeps EQ and gain settings repeatable from one session to the next. XLR and 1/4" metal jack connectors stand up to stage handling, and RCA phono inputs and outputs connect playback and recording gear directly. The chassis racks up when a fixed install calls for it, which suits small live venues, project studios, houses of worship, and multi-speaker installations.
